ATMTB-M2 Double Delay Modular Time Relay

Applications:

● For gradual switching of heavy powers(e.g. el.heating), prevents current

strokes in the main.

Features

● 2 Delay ON(2 time relays in one)

● Times t1 and t2 are independantly adjustable.

● Time scale 0.1S to 10 Days divided into 10 ranges.

● Relay status is indicated by LED.

● l Module, Din Rain mounting.

● Double Delay Modular Time Relay
